ERSASCOPE M & M plus XL

Inspection systems for the fast inspection of hidden solder joints on large boards

  • Inspection systems with two quick change lenses:
    - 90° BGA optics (approx. 280 µm clearance)
    - 0° MACROZOOM top view optics
  • Fast, stationary inspection of hidden solder joints
  • Integrated, dimmable LED lighting or external LED light source with goose neck fibre light and light brush
  • 5 Megapixel N-MOS colour camera with USB connection
  • XY table in XL version with fine adjust wheels, freely positionable under the optics
  • Optics extraction unit for the inspection of front components on particularly deep PCBs
  • Ideal for stationary inspection of large asseblies
  • Including Ersa ImageDoc v3 inspection software (basic version)
